- Wireless sound and vision
- Signal goes through walls and ceilings
- 5,8 Ghz Transmission
- Avoids interference from 2.4 GHz systems
- Built-in IR remote control extender
- Watch programs and movies on your (second) TV.
- Can be used with your DVD player, satellite receiver, decoder, etc
- Dual Source : The transmitter can be connected to two A/V devices
- Available with EU or UK power supply
- User Manual in English - Español - Italiano - Français - Nederlands - Deutsch
The Marmitek GigaVideo 570 enables you to transmit the signal of your Video recorder, DVD-player, DVD-recorder, Satellite receiver, set top box, PC etc. to your (second) TV without running wires.
With the GigaVideo570 you can also transmit films from your PC to the TV in the living room or bedroom, transmit MP3 audio to your Hifi System and monitor your baby or patients using your video camera, all from a remote location.
The built-in infrared extension feature enables you to control your A/V devices with your own remote control from the room where you are watching TV!
Using the 5.8 GHz frequency, you will usually experience no interference from i.g. wireless (2.4 Ghz WiFi) networks or a microwave oven.
How does the GigaVideo570™ work?
The set consists of a transmitter and a receiver. You connect the transmitter to the A/V output of your source (for instance settop box). Then you connect the receiver to your second TV. What’s more, you can keep operating the source which is located elsewhere with your own remote control using the infrared extender. GigaVideo570™ Transmitter
- Range: Up to 100m free field, up to 30m through walls and ceillings
- Power: 230VAC/50Hz, 7.2VDC adapter. 320mA
- Frequency: Audio/Video: 5.8GHz, 4 channels (A, B, C, D)
- IR: 433.92 MHz.
- A/V input: 1x Mini-DIN (A/V IN ) - 1x RCA (A/V IN 1x Video 2x Audio)
- A/V output: 1x Mini-DIN (AV OUT)
- Video input: 1Vpp (typ) 75 Ohm
- Audio input: 1Vpp (typ) 600 Ohm
- Audio: Stereo
- Dimensions: 140x100x140mm (with upright antenna)
GigaVideo570™ Receiver
- Power: 230VAC/50Hz, 7.2VDC adapter, 250mA
- Frequency: Audio/Video: 5.8GHz, 4 channels (A, B, C, D)
- A/V output: 1x Mini-DIN (AV OUT)
- RF output PAL-B/G: Channel 36
- RF output PAL-I: Channel 48
- Video output: 1Vpp (type) / 75 Ohm
- Audio output: 1Vpp (type) / 600 Ohm
- Audio: Stereo
- Dimensions: 92x58x20mm (with upright antenna)
- Download GigaVideo 570 Manual - (English - Español - Italiano - Français - Nederlands - Deutsch)
The Gigavideo 570 is available with EU power supply and with UK power supply, suitable for the specific type of outlet in your country. We automatically ship the right plug for the country of delivery.

- The IR Return channel is not compatible with some Digital Cable boxes.
The IR Frequency of your remote must be situated between 30 and 60 kHz.
|
